Qingxian process
Automatic feeding → (1) Ultrasonic cleaning with detergent → (2) Ultrasonic cleaning with detergent → (3) Ultrasonic cleaning with municipal water → (4) Ultrasonic cleaning with detergent → (5) Ultrasonic cleaning with pure water → (6) Ultrasonic cleaning with pure water → → (7) Ultrasonic cleaning with pure water → (8) Slow pulling with hot pure water → (9) Hot air drying → (10) Hot air drying → (11) Air cutting on the conveyor line → (12) Anti rust tank → (13) Cutting water tank → (14) Hot air drying → Automatic feeding.
Applicable objects
Precision gears, high-speed gears, connectors, structural components, etc
Product features
◆ Adopting a clamping type robotic arm for stable displacement.
The use of straight sliding rails in the horizontal direction makes the operation smoother.
◆ The lifting and throwing adopts a circular core structure, which can be lifted and thrown up and down for better cleaning effect.
◆ Equipped with initial filtration and intermediate filtration circulation systems.
Comprehensive cleaning process including ultrasonic cleaning, rinsing, drying, and oil immersion rust prevention.
◆ Equipped with initial filtration and intermediate filtration circulation systems.
Human machine interface, PLC automatic control system.
Tunnel furnace wind cutting constant temperature drying system.
The control box is integrated with the body for a more reasonable structure.
Suitable for cleaning the upper and lower covers for compression.
